Hastelloy B series valves corrosion resistance feature: It has the good corrosion resistance performance in the reducible sour medium and so on the hydrochloric acid, sulfuric acid, phosphoric acid.

Hastelloy Butterfly Valves Corrosion Resistance Feature
It has a fine corrosion resistance performance in includes chloridion etc. oxidized acid, in includes in the oxidant reducible acid, in the nitration mixture and so on with reducible acid and oxidized acid. Its prominent characteristic has the fine corrosion resistance in the strong corrosion oxidability and the reducible sour medium.

Hastelloy Butterfly Valves Applications
Hastelloy butterfly valves find applications across industries where corrosion resistance and high-temperature capabilities are vital. They are commonly used in chemical processing, oil and gas, power generation, pharmaceuticals, water treatment, aerospace, marine, mining, and biotechnology sectors. These valves excel in handling aggressive chemicals, acids, and corrosive media, making them ideal for critical processes that demand reliable and long-lasting performance in challenging environments. Their versatility and durability make them a preferred choice for controlling flow in various industrial applications.

Hastelloy Butterfly Valves Structure (Hastelloy C276 double offset butterfly valve for example)

NO. PARTSMATERIAL
1GasketPTFE
2Split ringB574 N10276
3StemB574 N10276
4ScrewB574 N10276
5SeatPTFE/RPTFE
6DiscA494 CW12MW
7PinB574 N10276
8Seat retainerA494 CW12MW
9BodyA494 CW12MW
10BearingPEEK
11PackingPTFE
12Gland bushingB574 N10276
13Double-end boltA193 B8M
14Hexagon nutA194 8M
15BracketA351 CF8M
16KeyUNS G10450
17Gearbox deviceCF8M / WCB
